6.Lowerallliftarmscompletely.
7.Removethesnapperpinandthecapfromthe
lift-arm-pivotyoke(Figure10).
g003975
Figure10
1.Snapperpin2.Cap
8.Forthefrontcuttingunits,slideacuttingunit
undertheliftarmwhileinsertingthecarrier-frame
shaftupintothelift-arm-pivotyoke(Figure11).
g003977
Figure11
1.Liftarm3.Lift-arm-pivotyoke
2.Carrier-frameshaft
9.Usethefollowingprocedureontherearcutting
unitswhentheheightofcutisabove1.9cm
(3/4inch).
A.Removethelynchpinandwashersecuring
thelift-arm-pivotshafttotheliftarmand
slidethelift-arm-pivotshaftoutofthelift
arm(Figure12).
g003979
Figure12
1.Lynchpinandwasher
B.Insertthelift-armyokeontothecarrier-frame
shaft(Figure11).
C.Insertthelift-armshaftintotheliftarmand
secureitwiththewasherandlynchpin
(Figure12).
10.Insertthecapoverthecarrier-frameshaftand
lift-armyoke.
11.Securethecapandthecarrier-frameshafttothe
lift-armyokewiththesnapperpin(Figure10).
Note:Usetheslotifasteeringcuttingunitis
desiredorusetheholeifthecuttingunitistobe
lockedinposition
12.Securethelift-armchaintothechainbracket
withthesnapperpin(Figure13).
Note:Usethenumberofchainlinksdescribed
intheOperator'sManualforthecuttingunit.
g003948
Figure13
1.Lift-armchain2.Chainbracket
13.Oncuttingunit4(leftfront)andcuttingunit5
(rightfront),insertthereel-motorhosesintothe
respectivehoseguide.
14.Coatthesplineshaftofthereelmotorwithclean
grease.
15.Oilthereel-motorO-ringandinstallitontothe
motorange.
16.Installthemotorbyrotatingitclockwisesothat
themotorangesclearthebolts(Figure14).
