Figure4

1.Offsetlifthook

TheChainLink,partno.106-2601,mountingbracket,

partno.105-5738and(2)capscrews,partno.323-6may

alsobeusedontheGreensmaster3250-Dtractionunit.

Installchainlinktotopofcuttingunitwithmounting

bracketand(2)capscrews.Torquecapscrewsto25-30

ft-lbs.(34-40N-m).Largeendoflinktohookon

tractionunitsuspension(

Figure5).

g011932

Figure5

1.Chainlink

2.Mountingbracket

UsingtheCuttingUnitProp

NoPartsRequired

Procedure

Wheneverthecuttingunithastobetippedtoexpose

thebedknife/reel,propuptherearofthecuttingunit

tomakesurethenutsonthebackendofthebedbar

adjustingscrewsarenotrestingontheworksurface

(Figure6).

Figure6

1.Prop(notprovided)2.Bedknifeadjustingscrew

nut(2)

InstallingtheCounterWeights

NoPartsRequired

Procedure

Thecuttingunitsareshippedwiththecounterweight

mountedtotheleftendandthemotormountanddrive

couplermountedtotherightendofthecuttingunit.

Tomountthecuttingunitintherightfrontposition,

proceedasfollows:

1.Removethe2capscrewssecuringthecounterweight

totheleftendofthecuttingunit.Removethe

counterweight(Figure7).
