Figure10
1.Bedbaradjustingscrew
2.Tiltthemoweronbacktoexposethebedknifeand
reel.
Important:Makesurenutsonbackendof
bedbaradjustingscrewsarenotrestingonwork
surface(Figure6).
3.Atoneendofreel,insertalongstripofnewspaper
betweenreelandbedknife(Figure11).Whileslowly
rotatingreelforward,turnbedbaradjustingscrew
clockwise(onsameendofreel,oneclickatatime,
untilpaperispinchedlightly,wheninsertedfromthe
front,paralleltothebedknife.Aslightdragwillbe
notedasthepaperispulled.
Figure11
Note:Eachtimetheadjustingscrewisrotatedone
clickclockwise,thebedknifemoves.0007in.closer
tothereel.Donotovertightentheadjusting
screws.
4.Checkforlightcontactatotherendofreelusing
paperandadjustasrequired.
5.Aftertheadjustmentisaccomplished,checktosee
ifthereelcanpinchpaperwheninsertedfromthe
frontandcutthepaperwheninsertedatarightangle
tothebedknife(
Figure11).Itshouldbepossibleto
cutthepaperwithminimumcontactbetweenthe
bedknifeandthereelblades.Shouldexcessivereel
dragbeevident,itwillbeeithernecessarytobacklap
orregrindthecuttingunittoachievethesharpedges
neededforprecisioncutting(seetheToroReel
SharpeningManual).
6
AdjustingtheRearRoller
NoPartsRequired
Procedure
1.Adjusttherearrollerbrackets(Figure12or
Figure13)totheloworhighpositiondependingon
thedesiredheightofcutrange.
Positionthespacerabovethesideplatemounting
ange(factorysetting)whenheightofcutsettings
rangefrom1/16to1/4inch(
Figure12).
Figure12
1.Spacer3.Sideplatemountingange
2.Rollerbracket
Positionthespacerbelowthesideplatemounting
angewhenheightofcutsettingsrangefrom1/8"
to1"(Figure13).
Figure13
1.Spacer3.Sideplatemountingange
2.Rollerbracket
7
