Figure3

1.Fender

3.Securerearofeachtaillightbrackettorearof

framebracketswitha5/16x1in.bolt,.344”I.D.

atwasherandlocknut,asshowninFigure3.

Figure4

1.Fender

2.Supportplate

4.Looselysecureafendertoeachsideofframewith

asupportplate,(5)3/8x1–1/4in.bolts,anda

locknutasshowninFigure4.

Note:Weldnutsareinplacetosecure(4)ofthe

bolts.

5.Tightenallfasteners.

InstalltheWheels

Partsneededforthisprocedure:

10Wheelnut

2Frontwheel

10Wheelnut

2Rearwheel

Procedure

1.Removelugnutssecuringwheelstowheelbrackets.

Retainlugnuts.

2.Mountwheelsandinstalllugnuts.Torquelugnuts

to45–65ft-lb.

Figure5

1.Wheel2.Wheelnut
