Toro 07360 - Controls System Maintenance; Adjusting Accelerator Pedal

Figure65
1.Fanbelt2.Idlerpulley
ControlsSystem
Maintenance
AdjustingAcceleratorPedal
1.Positionvehicleonlevelsurface,stopengineand
engagetheparkingbrake.
2.Adjustballjointonacceleratorcable(Figure66)to
allow.200”–.350”ofclearancebetweenaccelerator
pedalarmandtopofdiamondtreadoorplate
(Figure67),whena20lb.forceisappliedtocenter
ofpedal.Tightenlocknut.
Note:Enginemustnotberunningandreturn
springmustbeattached.
Thegovernorispresetatthefactorytoa
maximumenginespeedof3650rpm.Ifthe
speedisnotcorrect,refertotheWorkman
ServiceManualorcontactyourauthorizedToro
Dealer/Distributorforassistance.
Figure66
1.Acceleratorcable2.Balljoint
