Toro 07360 - Full Bed Removal; Re-Install the Full Bed

7
FullBedRemoval
NoPartsRequired
Procedure
1.Startengine.Engagehydraulicliftleverandlower
beduntilcylindersarelooseinslots.Releaseliftlever
andturnoffengine.
2.Removelynchpinsfromouterendsofcylinderrod
clevispins(Figure11).
Figure11
1.Bedmountingplate4.Lynchpin
2.Cylinderrodend5.Rearslots(Fullbed)
3.Clevispin6.Frontslots(2/3bed)
3.Removeclevispinssecuringcylinderrodendsto
bedmountingplatesbypushingpinstowardsinside
(Figure11).
4.Removelynchpinsandclevispinssecuringpivot
bracketstoframechannels(Figure11).
5.Liftbedoffvehicle.
Thefullbedweighsapproximately325pounds,
sodonottrytoinstallorremoveitbyyourself.
Useanoverheadhoistorgetthehelpoftwoor
threeotherpeople.
6.Storecylindersinstorageclips.Engagehydrauliclift
lockleveronvehicletopreventaccidentalextension
ofliftcylinders.
8
Re-InstalltheFullBed
NoPartsRequired
Procedure
Note:Ifbedsideswillbeinstalledonatbed,itis
easiertoinstallthembeforebedisinstalledonvehicle.
Note:Assurerearpivotplatesareboltedtothebed
frame/channelsothatlowerendanglestotherear
(Figure12).
Figure12
1.Leftrearcornerofbed4.Clevispin
2.Vehicleframechannel
5.Lynchpin
3.Pivotplate
Note:Makesurespacerbracketsandwearblocks
(Figure13)areinstalledorradiatorcovermaybe
damaged.Carriageboltsheadstobepositionedinside
themachine.
