Controls
Control Panel
g435396
Figure 7
1. Horn switch 6. Parking-brake lever
2. Light switch
7. USB power point
3. Display 8. Accelerator pedal
4. Direction selector 9. Brake pedal
5. Key switch
Accelerator Pedal
Use the accelerator pedal ( Figure 7 ) to vary ground
speed of the machine. Pressing down the accelerator
pedal starts the machine. Pressing the pedal farther
increases ground speed. Releasing the pedal slows
the machine, and the machine shuts of f.
The maximum forward speed in performance mode is
26 km/h (16 mph) as shown in Figure 18 .
The maximum forward speed in economy mode is 19
km/h (12 mph) as shown in Figure 18 .
Brake Pedal
Use the brake pedal to stop or slow the machine.
W ARNING
Operating a machine with worn or incorrectly
adjusted brakes can result in personal injury .
If the brake pedal travels within 25 mm (1
inch) of the machine oor board, adjust or
repair the brakes.
12
