g319306
Figure 47
1. Speed clip
4. Headlight
2. Opening in the bumper
5. Harness electrical
connector
3. Adjustment screw 6. Lamp assembly
4. Remove the speed clips that secure the
headlight to the headlight bracket ( Figure 47 ).
Note: Retain all parts for installation of the new
headlight.
5. Remove the headlight assembly by moving it
forward through the opening in the front bumper
( Figure 47 ).
6. Install the new headlight through the opening in
the bumper ( Figure 47 ).
Note: Ensure the adjustment posts are lined up
with the holes in the mounting bracket behind
the bumper .
7. Secure the headlight assembly with the speed
clips that you removed in step 4 .
8. Connect the electrical connector for the harness
to the connector of the lamp assembly ( Figure
47 ).
9. Adjust the headlights to direct the beams to
the desired position, refer to Adjusting the
Headlights ( page 41 ) .
Adjusting the Headlights
Use the following procedure to adjust the headlight
beam position whenever a headlight assembly is
replaced or removed.
1. Park the machine on a level surface with the
headlights approximately 7.6 m (25 ft) from a
wall ( Figure 48 ).
2. Measure the distance from the oor to the center
of the headlight and make a mark on the wall at
the same height.
3. T urn the key switch to the O N position, and turn
on the headlights.
4. T ake note of where the headlights aim on the
wall.
The brightest part of the headlight beam should
be 20 cm (8 inches) below the mark placed on
the wall ( Figure 48 ).
g298100
Figure 48
5. At the back of the headlight assembly , rotate
adjustment screws ( Figure 47 ) to pivot the
headlight assembly and align the position of the
cast beam.
6. Close the hood.
41
