Cleaning

CleaningundertheMower

Deck

ServiceInterval:Beforeeachuseordaily

1.Parkthemachineonalevelsurface,disengage

theblade-controlswitch(PTO),andengagethe

parkingbrake.

2.Shutofftheengine,removethekey,andwait

forallmovingpartstostopbeforeleavingthe

operatingposition.

3.RaisethemowerdecktotheTRANSPORT

position.

CleaningtheSuspension

System

Usecompressedairtocleanthesuspensionsystem.

Note:Donotcleantheshockassemblieswith

pressurizedwater(Figure87).

g195820

Figure87

DisposingofWaste

Engineoil,batteries,hydraulicuid,andengine

coolantarepollutantstotheenvironment.Disposeof

theseaccordingtoyourstateandlocalregulations.
