Figure89
FrontAxle
1.Front-axlehousing4.Pinionhousing
2.Oil-servicingequipment5.Sightport
3.Fillplug
Figure90
RearAxle
1.Rear-axlehousing4.Fillplug
2.Forward
5.Sightport
3.Oil-servicingequipment
6.Filltheaxleswiththespeciedoilthroughthesight
portuntiltheoilislevelwiththethreadsatthebottom
oftheport(Figure89andFigure90).
7.Waitafewminutesfortheoiltosettle,thenaddmore
oilasnecessary.
Note:Continuetoaddoiluntiltheoillevelstabilizes
andisatthebottomofthethreadsofthesightport.
8.Installthellplugsintothesightportsofthepinion
housingsfortheaxles(Figure89andFigure90).
