Lubrication
GreasingtheBearingsand
Bushings
Themachinehasgreasettingsthatmustbelubricated
regularlywithNo.2GeneralPurposeLithiumBase
Grease.Ifthemachineisoperatedundernormal
conditions,lubricateallbearingsandbushingsafter
every50hoursofoperationorimmediatelyafterevery
washing.
Thegreasettinglocationsandquantitiesare:
TractionUnit
ServiceInterval:Every50hours
•Brakeshaftpivotbearings(5)(Figure36)
•Tractionpedalpivotbushing(1)(Figure37)
•Frontandrearaxlepivotbushings(2)(Figure38)
•Steeringcylinderballjoints(2)(Figure39)
•Tierodballjoints(2)(Figure39)
•Kingpinbushings(2)(Figure39).
Thetopttingonthekingpinshould
onlybelubricatedannually(2pumps).
Figure36
Figure37
Figure38
Figure39
