Toro 30857 - Replacing the Warning Decal for CE Compliance; Installing the Hood Latch (CE Only)

1
ReplacingtheWarningDecal
forCECompliance
Partsneededforthisprocedure:
1Warningdecal
Procedure
OnmachinesrequiringEuropeanCECompliance,
replacethewarningdecal,partno.112–5297withthe
warningdecalpartno.112-5298.
2
InstallingtheHoodLatch(CE
Only)
Partsneededforthisprocedure:
1Lockbracket
2Rivet
1Washer
1
Screw,1/4x2inches
1
Locknut,1/4inch
Procedure
1.Unhookthehoodlatchfromthehoodlatchbracket.
2.Removethe(2)rivetssecuringthehoodlatchbracket
tothehood(
Figure3).Removethehoodlatch
bracketfromthehood.
G012628
1
2
Figure3
1.Hoodlatchbracket2.Rivets
3.Whilealigningthemountingholes,positiontheCE
lockbracketandthehoodlatchbracketontothe
hood.Thelockbracketmustbeagainstthehood
(Figure4).Donotremoveboltandnutassembly
fromthelockbracketarm.
G012629
1
2
Figure4
1.CElockbracket
2.Boltandnutassembly
4.Alignthewasherswiththeholesontheinsideofthe
hood.
5.Rivetthebracketsandthewasherstothehood
(Figure4).
6.Hookthelatchontothehoodlatchbracket
(
Figure5).
