ElectricalSystem
Maintenance
ChargingandConnectingthe
Battery
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
1.Unlatchandraisetheoperator'sconsolepanel
(Figure37).
Figure37
1.Operator'sconsolepanel
2.Latch
DANGER
Batteryelectrolytecontainssulfuricacidwhich
isadeadlypoisonandcausessevereburns.
•Donotdrinkelectrolyteandavoidcontact
withskin,eyesorclothing.Wearsafety
glassestoshieldyoureyesandrubbergloves
toprotectyourhands.
•Fillthebatterywherecleanwaterisalways
availableforushingtheskin.
2.Connecta3to4amp.batterychargertothebattery
posts.Chargethebatteryatarateof3to4amperes
for4to8hours.
3.Whenthebatteryischarged,disconnectthecharger
fromtheelectricaloutletandbatteryposts.
WARNING
Chargingthebatteryproducesgassesthatcan
explode.
Neversmokenearthebatteryandkeepsparks
andamesawayfrombattery.
4.Installthepositivecable(red)tothepositive(+)
terminalandthenegativecable(black)tothenegative
(-)terminalofthebattery(
Figure38).Securecables
topostswithcapscrewsandnuts.Makesurethatthe
positive(+)terminalisallofthewayontothepost
andthecableispositionedsnugtothebattery.The
cablemustnotcontactthebatterycover.Slidethe
rubberbootoverthepositiveterminaltopreventa
possibleshortfromoccurring.
Figure38
1.Positivebatterycable2.Negativebatterycable
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
