Toro 30857 - Checking Fluid Levels; Product Overview; Controls

5
CheckingFluidLevels
NoPartsRequired
Procedure
1.Checktherearaxlelubricantlevelbeforetheengine
isrststarted,refertoCheckingtheRearAxle
LubricantinDriveSystemMaintenance.
2.Checkthehydraulicuidlevelbeforetheengineis
rststarted,refertoCheckingtheHydraulicFluid
LevelinOperation.
3.Checktheengineoillevelbeforeandaftertheengine
isrststarted,refertoCheckingtheEngineOil
LevelinOperation.
ProductOverview
Controls
BrakePedals
Twofootpedals(Figure8)operateindividualwheel
brakesforturningassistanceandtoaidinobtaining
bettersidehilltraction.
PedalLockingLatch
Thepedallockinglatch(Figure8)connectsthepedals
togethertoengagetheparkingbrake.
ParkingBrakePedal
Toengagetheparkingbrake,(Figure8)connectthe
pedalstogetherwiththepedallockinglatch,pushdown
ontherightbrakepedalwhileengagingthetoepedal.To
releasetheparkingbrake,pressoneofthebrakepedals
untiltheparkingbrakelatchretracts.
Figure8
1.Brakepedal4.Tractionpedal
2.Pedallockinglatch5.Tiltsteeringpedal
3.Parkingbrakepedal
TractionPedal
Thetractionpedal(Figure8)controlsforwardand
reverseoperation.Depressthetopofthepedaltomove
forwardandthebottomtomovebackward.Ground
speeddependsonhowfarthepedalisdepressed.For
noload,maximumgroundspeed,fullydepressthepedal
whilethethrottleisinFast.
Tostop,reduceyourfootpressureonthetractionpedal
andallowittoreturntothecenterposition.
TiltSteeringPedal
Totiltthesteeringwheeltowardsyou,pressthefoot
pedal(Figure8)down,andpullthesteeringtower
15
