Toro 30857 - Installing the Throttle Stop for CE Compliance When Installing Optional High Lift Blades; Greasing the Machine

G012630
1
Figure5
1.Hoodlatch
7.Screwtheboltintotheotherarmofhoodlock
brackettolockthelatchinposition(Figure6).
Tightenboltsecurelybutdonottightennut.
G012631
1
2
3
Figure6
1.Bolt
3.Armofhoodlockbracket
2.Nut
3
InstallingtheThrottleStop
forCECompliancewhen
InstallingOptionalHighLift
Blades
Partsneededforthisprocedure:
1Throttlestop
1
Setscrew
Procedure
1.Loosenthesetscrewonthethrottlestop(
Figure7).
2.Slidethethrottlestopontothehighidlestopscrew
(Figure7).Thechamferedendofthethrottlestopis
tobepositionedoutward.
Figure7
1.Throttlestop
2.Setscrew
3.Starttheengineandallowittorunfor5to10
minutes.
4.Adjustthehighidleto2650rpmwiththecutting
unitsdisengaged.
5.Tightenthesetscrew .
6.Applyadhesiveintothesetscrewtoprevent
tampering.
4
GreasingtheMachine
NoPartsRequired
Procedure
Beforethemachineisoperated,itmustbegreasedto
ensureproperlubrication.RefertoLubricationsection.
Failuretoproperlygreasethemachinewillresultin
prematurefailureofcriticalparts.
14
