Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Warningdecal1
Replacethewarningdecal(CE
machinesonly).
Hood-latchbracket1
Rivet2
Washer1
Screw(1/4x2inches)
1
2
Locknut(1/4inch)
1
Installthehoodlatch.
3
Nopartsrequired
–
Adjusttherollerscraper(optional).
4
Nopartsrequired
–
Installthemulchingbafe(optional).
5
Nopartsrequired
–
Preparethemachine.
MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Reviewbeforeoperatingthemachine.
Engineowner’smanual1
Refertothemanualforadditionalmaintenanceinformation.
OperatorTrainingMaterial
1
Reviewbeforeoperatingthemachine.
DeclarationofConformity
1
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
ReplacingtheWarning
Decal(CEMachinesOnly)
Partsneededforthisprocedure:
1Warningdecal
Procedure
OnmachinesrequiringEuropeanCEcompliance,
replacewarningdecalPartNo.112-5297withwarning
decalPartNo.127-6447(for4500seriesmachines)or
decalPartNo.127-6448(for4700seriesmachines).
