Toro 30874 - Locating the Tie-Down Points

g036666
g225685
Figure28
1.Bypassvalves
2.Rotateeachvalve3turnscounter-clockwiseto
openandallowtheoiltobypassinternally.
Note:Donotopenmorethan3turns.Because
uidisbypassed,youcanslowlymovethe
machinewithoutdamagingthetransmission.
3.Closethebypassvalvesbeforestartingthe
engine.
4.Torqueto70N∙m(52ft-lb)toclosethevalve.
Important:Topushortowthemachineinreverse,
youmustbypassthecheckvalveinthe4-wheel
drivemanifold.Tobypassthecheckvalve,
connectahoseassemblytothereversetraction
pressuretestport,locatedonthehydrostat,and
ontheportlocatedbetweenportsM8andP2on
thereartractionmanifold,whichislocatedbehind
thefronttire.Thehoseassemblyincludes1hose
(PartNo.95-8843),2couplerttings(PartNo.
95-0985),and2hydraulicttings(PartNo.340-77).
LocatingtheTie-Down
Points
Note:Useproperly-ratedDOT-approvedstrapsin4
cornerstotiedownthemachine.
•Oneachsideoftheframebytheoperator’s
platform
•Ontherearbumper
g036664
Figure29
g036665
Figure30
37
