InstallingtheHoodLatch
Partsneededforthisprocedure:
1Hood-latchbracket
2Rivet
1Washer
1
Screw(1/4x2inches)
1
Locknut(1/4inch)
Procedure
1.Unhookthehoodlatchfromthehood-latch
bracket.
2.Removethe2rivetssecuringthehood-latch
brackettothehood(Figure3).Removethe
hood-latchbracketfromthehood.
g012628
Figure3
1.Hood-latchbracket2.Rivets
3.Openthehoodtoaccessthebacksideofthe
holes.
4.AligntheholesintheCElockbracketandthe
hood-latchbracketwiththeholesinthehood
(Figure4).
Note:Alignthelockbracketushagainstthe
hoodandthehood-latchbracketushagainst
thelockbracket.Donotremovetheboltandnut
fromthelock-bracketarm.
g012629
Figure4
1.CElockbracket
2.Boltandnut
5.Insideofthehood,alignthewasherswiththe
holesinthehood.
6.Rivetthebracketsandthewasherstothehood
(Figure4).
7.Closethehoodandhookthelatchontothe
hood-latchbracket(Figure5).
g012630
Figure5
1.Hoodlatch
8.Screwtheboltintotheotherarmofthe
hood-latchbrackettolockthelatchinposition
(Figure6).Tightentheboltbutdonottighten
thenut.
