Toro 41594 Installation Instructions

g207762
Figure63
1.Floorplatechannel3.Dataplate
2.Rivet
11
InstallingtheUndercarriage
ShroudandForwardHeat
Shield
NoPartsRequired
InstallingtheUndercarriage
Shroud
G032041
g032041
Figure64
1.Aligntheundercarriageshroudtothebottom
chassisofthemachine(Figure65).
g032043
Figure65
1.Enginemounts
4.Flangelocknuts(5/16
inch)
2.Bolt—shownforclarity5.Frontofthemachine
3.Undercarriageshroud
2.Sliptheforwardmountingangesofthe
undercarriageshroudovertheboltsandcarriage
boltsattheengine-mountbracketsofthe
machine(Figure65).
3.Assembletheundercarriageshroudtothe
engine-mountbracketsandbolts(Figure
65)withthe4angelocknuts(5/16inch)
thatyouremovedinstep2ofRemovingthe
UndercarriageShroud(page4).
4.Aligntheholesintherearpartofthe
undercarriageshroudwiththeholesinthe
chassis(Figure66).
25
