g028168

Figure3

1.Forwardheatshield

3.Frontofthemachine

2.Hex-headboltsand

washers

RemovingtheUndercarriage

Shroud

G032041

g032041

Figure4

1.Removethefollowinghardwarethatsecuresthe

rearoftheundercarriageshroudtothechassis

ofthemachine(Figure5):

•2016machines—7ange-headbolts(5/16

x7/8inch)and7washers(5/16inch)

•2017andlatermachines—5ange-head

bolts(5/16x7/8inch)and5washers(5/16

inch)

Note:Retaintheange-headboltsand

washersforinstallationinstep5ofRemoving

theUndercarriageShroud(page4).

g208653

Figure5

2017machineshown;2016machinesaresimilar

1.Undercarriageshroud

3.Flange-headbolts(5/16x

7/8inch)

2.Washers(5/16inch)4.Frontofthemachine

2.Removethe4angelocknuts(5/16inch)from

theboltsandcarriageboltsthatsecurethe

supportstrapsoftheundercarriageshroud

totheengine-mountbracketsofthemachine

(Figure6).

Note:Donotremovetheboltsfrom

themachine.Retaintheangelocknuts

forinstallationinstep3ofInstallingthe

UndercarriageShroud(page25).
