Toro 71254 - Safety Interlock Testing and Manual Pushing

Figure12
1.KeyChoiceswitch
DANGER
Youcouldbackoverachildorbystanderwhilethe
mowerbladesorotherattachmentisengagedand
causeseriousinjuryordeath.
•Donotmowinreverseunlessitisabsolutely
necessary.
•DonotinserttheKeyChoicekeyunlessitis
absolutelynecessary.
•Alwayslookbackwardanddownbeforebacking
up.
•UsetheKeyChoiceswitchonlyifyouarecertain
nochildrenorotherbystanderswillenterthe
mowingarea.
•Beveryobservantafterdeactivatingtheinterlock
becausethesoundoftheenginemayprevent
youfromnoticingthatachildorbystanderhas
enteredtheworkarea.
•AlwaysremoveboththeignitionandKeyChoice
keysandputtheminasafeplaceoutofthe
reachofchildrenorunauthorizeduserswhen
leavingthemachineunattended.
1.Engagethebladecontrol(PTO).
2.InserttheKeyChoicekeyintotheswitch(Figure12).
3.TurntheKeyChoicekey.
Note:Aredlightonthefrontconsole(Figure5)turns
on,indicatingthattheinterlockisdisabled.
4.Shiftthetraction-controlswitchintoReverseand
completeyourtask.
5.Disengagethebladecontrol(PTO)toactivatethe
interlock.
6.RemovetheKeyChoicekeyandputitinasafeplace
outofthereachofchildren.
TestingtheSafetyInterlock
System
CAUTION
Ifsafetyinterlockswitchesaredisconnectedor
damaged,themachinecouldoperateunexpectedly,
causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlockswitches
dailyandreplaceanydamagedswitchesbefore
operatingthemachine.
•Replaceswitchesevery2yearsregardlessof
whethertheyareoperatingproperlyornot.
Testthesafetysystembeforeyouusethemachineeachtime.
Ifthesafetyinterlocksystemdoesnotoperateasdescribed
below,haveanAuthorizedServiceDealerrepairthesafety
interlocksystemimmediately.Whilesittingintheseat,
performthefollowingchecks:
1.Shiftthebladecontrol(PTO)toEngageandturnthe
ignitionkeytoStart:Theengineshouldnotcrank.
2.Shiftthebladecontrol(PTO)toDisengage,remove
yourfootfromthetraction-controlpedal,andstart
theengine.Whiletheengineisrunning,shiftthe
bladecontrol(PTO)switchtoEngageandmovethe
traction-controlpedaltoReverse:Thebladecontrol
(PTO)shoulddisengage.
3.Shiftthebladecontrol(PTO)toDisengageand
removeyourfootfromthetraction-controlpedal.Start
theengine,shiftthebladecontrol(PTO)switchto
Engage,andturntheKeyChoicekeyandreleaseit:The
operating-in-reversewarninglightshouldilluminate.
4.Shiftthebladecontrol(PTO)toDisengage:The
operating-in-reversewarninglightshouldturnoff.
PushingtheMachineManually
Important:Alwayspushthemachinemanually.Never
towthemachinebecauseyoumaydamagethetransaxle.
ToPushtheMachine
1.Disengagethebladecontrol(PTO).
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.PullthedrivecontrolouttothePushposition.
