Toro 71255 - Testing the Safety Interlock System; Pushing the Tractor Manually

Ifyouneedtousethebladecontrol(PTO)while
backingup,turnofftheinterlockfeatureusingthe
KeyChoiceswitchlocatedneartheseatbracket
(
Figure12).
1
G006903
Figure12
1.KeyChoiceswitch
DANGER
Youcouldbackoverachildorbystanderwhilethe
mowerbladesorotherattachmentisengagedand
causeseriousinjuryordeath.
•Donotmowinreverseunlessitisabsolutely
necessary.
•DonotinserttheKeyChoicekeyunlessitis
absolutelynecessary.
•Alwayslookbackwardanddownbeforebacking
up.
•UsetheKeyChoiceswitchonlyifyouare
certainnochildrenorotherbystanderswill
enterthemowingarea.
•Beveryobservantafterdeactivatingthe
interlockbecausethesoundoftheengine
maypreventyoufromnoticingthatachildor
bystanderhasenteredtheworkarea.
•AlwaysremoveboththeignitionandKeyChoice
keysandputtheminasafeplaceoutofthe
reachofchildrenorunauthorizeduserswhen
leavingthetractorunattended.
1.Engagethebladecontrol(PTO).
2.InserttheKeyChoicekeyintotheswitch(Figure12).
3.TurntheKeyChoicekey.
Note:Aredlightonthefrontconsole(Figure5)
turnson,indicatingthattheinterlockisdisabled.
4.ShiftthetractioncontrolswitchintoReverseand
completeyourtask.
5.Disengagethebladecontrol(PTO)toactivatethe
interlock.
6.RemovetheKeyChoicekeyandputitinasafeplace
outofthereachofchildren.
TestingtheSafetyInterlock
System
CAUTION
Ifsafetyinterlockswitchesaredisconnectedor
damaged,thetractorcouldoperateunexpectedly,
causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlockswitches
dailyandreplaceanydamagedswitchesbefore
operatingthetractor.
•Replaceswitchesevery2yearsregardlessof
whethertheyareoperatingproperlyornot.
Testthesafetysystembeforeyouusethetractoreach
time.Ifthesafetyinterlocksystemdoesnotoperateas
describedbelow ,haveanAuthorizedServiceDealer
repairthesafetyinterlocksystemimmediately.While
sittingintheseat,performthefollowingchecks:
1.Shiftthebladecontrol(PTO)toEngageandturn
theignitionkeytoStart:Theengineshouldnot
crank.
2.Shiftthebladecontrol(PTO)toDisengage,remove
yourfootfromthetractioncontrolpedal,andstart
theengine.Whiletheengineisrunning,shiftthe
bladecontrol(PTO)switchtoEngageandmove
thetractioncontrolpedaltoReverse:Theblade
control(PTO)shoulddisengage.
3.Shiftthebladecontrol(PTO)toDisengage,engage
thetractioncontrolpedalwithyourfoot,andstart
theengine:Theengineshouldnotstart.
4.Withthebladecontrol(PTO)intheDisengage
position,removeyourfootfromthetractioncontrol
pedal.Starttheengine,shiftthebladecontrol
(PTO)switchtoEngage,andturntheKeyChoice
keyandreleaseit:Theoperating-in-reversewarning
lightshouldilluminate.
5.Shiftthebladecontrol(PTO)toDisengage:The
operating-in-reversewarninglightshouldturnoff.
PushingtheTractorManually
Important:Alwayspushthetractormanually.
Nevertowthetractorbecauseyoumaydamage
thetransaxle.
ToPushtheTractor
1.Disengagethebladecontrol(PTO).
15
