Toro 72902TE - Pre-Maintenance Procedures; Using the Z Stand

MaintenanceService
Interval
MaintenanceProcedure
Every500hours
•Replacethesafetyairlter(moreoftenindirtyordustyconditions).
•Replacethefuellter(moreoftenindusty,dirtyconditions).
•Checkthewheellug-nuttorque.
•Checkthewheel-hubslotted-nuttorque.
•Adjustthecaster-pivotbearing.
•Adjusttheparkingbrake.
•Aftertheinitialchange—changethehydraulic-systemltersanduidwhenusing
Toro®HYPR-OIL™500uid.(Changeitmoreoftenunderdirtyordustyconditions)
Monthly
•Checkthebatterycharge.
Yearly
•Greasethepump-belt-idlerarm.
•Repackthecaster-wheelbearings(moreoftenindirtyordustyconditions).
•Greasingthecaster-wheelhubs.
Yearlyorbeforestorage
•Paintchippedsurfaces.
•Checkallmaintenanceprocedureslistedabovebeforestorage.
Important:Refertoyourengineowner'smanualforadditionalmaintenanceprocedures.
CAUTION
Ifyouleavethekeyintheswitch,someonecouldaccidentlystarttheengineandseriously
injureyouorotherbystanders.
Shutofftheengineandremovethekeyfromtheswitchbeforeyouperformanymaintenance.
Pre-Maintenance
Procedures
UsingtheZStand
TM
TheZStandraisesthefrontendofthemachineto
allowyoutocleanthemowerandremovetheblades.
WARNING
Themachinecouldfallontosomeoneand
causeseriousinjuryordeath.
•Useextremecautionwhenoperatingthe
machineontheZStand.
•UsetheZStandonlyforcleaningthe
mowerandremovingtheblades.
•DonotkeepthemachineontheZStand
forextendedperiodsoftime.
•Alwaysshutofftheengine,setthe
parkingbrake,andremovethekeybefore
performinganymaintenancetothemower.
DrivingupontotheZStand
Important:UsetheZStandonalevelsurface.
1.Raisethemowerdecktothetransportposition.
2.Removethebracketpin(Figure44).
g001811
Figure44
1.ZStand4.Bottomofslot
2.Bracketpin5.Latch
3.Bracket
3.Raisethelatch.
42
