InstallingtheBattery
Note:Positionthebatteryinthetraywiththeterminal
postsoppositefromthehydraulictank(Figure68).
g032526
Figure68
ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequires
nomaintenance,however,ifafuseblowscheckthe
component/circuitforamalfunctionorshort.
Thefusesarelocatedontheconsoletotherightof
theseat(Figure69).
1.Toreplacethefuses,pulloutonthefuseto
removeit.
2.Installanewfuse(Figure69).
g008966
Figure69
1.Optionalaccessory(15A)4.Main(25A)
2.Charge(25A)
5.Console
3.PTO(10A)
