Toro 72902TE - Adjusting the Anti-Scalp Rollers

AdjustingtheHeight-of-CutPin
Theheight-of-cutisadjustedfrom25to140mm(1
to5-1/2inches)in6mm(1/4inch)incrementsby
relocatingtheclevispinintodifferentholelocations.
1.Movethetransportlocktothelockposition.
2.Pushonthedeck-liftpedalwithyourfoot,and
raisethemowerdecktothetransportposition
(alsothe140mm(5-1/2inch)cuttingheight
position)asshowninFigure29.
3.Toadjust,rotatethepin90degreesandremove
thepinfromtheheight-of-cutbracket(Figure
29).
4.Selectaholeintheheight-of-cutbracket
correspondingtotheheight-of-cutdesired,and
insertthepin(Figure29).
5.Pushonthedecklift,pullbackonthetransport
lock,andslowlylowerthemowerdeck.
g027343
Figure29
1.Deck-liftpedal
3.Transportlock
2.Cut-of-heightpin
AdjustingtheAnti-Scalp
Rollers
MachineswithSideDischarge
Wheneveryouchangetheheight-of-cut,adjustthe
heightoftheanti-scalprollers.
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andengagetheparking
brake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Adjusttheanti-scalprollersasshowninFigure
30,Figure31,andFigure32.
g029955
Figure30
1.Anti-scalproller4.Flangenut
2.Spacer
5.Bolt
3.Bushing
g029956
Figure31
1.Anti-scalproller3.Flangenut
2.Bushing4.Bolt
32
