Toro 72902TE - Releasing the Mower-Deck Curtain

4.Swingthestandfootoutfrontandslideit
towardmachine,intothebottomofslot(Figure
44andFigure45).
g001812
Figure45
1.ZStand(positionedinslot)
3.Latchrestingonpivottab
2.Crackinsidewalkorturf
5.Setthefootofthestandonthegroundandrest
thelatchonthepivottab(Figure45).
6.Starttheengineandputitathalfthrottle.
Note:Forbestresults,placethefootofthe
standintotheseamsinsidewalksorintotheturf
(Figure45).
7.Drivethemachineontothestand.Stopwhen
thelatchdropsoverthetabintothelocked
position(Figure45).
8.Engagetheparkingbrake,shutofftheengine,
andremovethekey.
9.Chockorblockthedrivewheels.
WARNING
Theparkingbrakemaynotholdthe
machineparkedontheZStandand
couldcausepersonalinjuryorproperty
damage.
DonotparkontheZStandunlessthe
wheelsarechockedorblocked.
10.Performthemaintenance.
DrivingofftheZStand
1.Removethechocksorblocks.
2.Raisethelatchtotheunlockedposition(Figure
46).
g001813
Figure46
1.ZStand
3.Lockedposition
2.Latch4.Unlockedposition
3.Starttheengineandplaceitathalfthrottle.
Disengagetheparkingbrake.
4.Slowlydrivebackwardoffthestand.
5.Returnthestandtoitsrestposition(Figure44).
ReleasingtheMower-Deck
Curtain
Loosenthebottomboltofthecurtaintorelease
themower-deckcurtainandgetaccesstothetop
ofthemowerdeck(Figure47).Afterperforming
maintenance,installthecurtainandtightenthebolt.
g027945
Figure47
1.Bolt
2.Curtain
