EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Every25hours—Servicetheair
cleanerfoamelement.(Serviceit
morefrequentlywhenoperatingthe
machineindustyordirtyconditions.)
Every100hours—Servicetheaircleaner
paperelement.(Serviceitmorefrequently
whenoperatingthemachineindustyordirty
conditions.)
1.Parkthemachineonalevelsurface.
2.Disengagetheblades(PTO).
3.Settheparkingbrake.
4.Stoptheengineandwaitforallmovingpartsto
stop.
5.Removetheignitionkey.
6.Allowtheenginetocool.
7.Openthehood.
RemovingtheFoamandPaper
Elements
1.Cleanaroundtheaircleanertopreventdirtfrom
gettingintotheengineandcausingdamage.
2.Pullupontheaircleanercoverhandleand
rotateittowardtheengine(Figure22).
g008279
Figure22
1.Aircleanercover2.Aircleanercoverhandle
3.Removetheaircleanercover.
4.Carefullyslidethepaperelementandthefoam
elementfromtheblowerhousing(Figure23).
g008280
Figure23
1.Paperelement4.Tab
2.Foamelement
5.Slot
3.Aircleanercover6.Blowerhousing
CleaningtheFoamandPaper
Elements
FoamElement
1.Washthefoamelementinliquidsoapandwarm
waterandrinseitthoroughly.
2.Drytheelementbysqueezingitinacleancloth.
Note:Donotoilthefoamelement.
Important:Replacethefoamelementifitistorn
orworn.
PaperElement
1.Lightlytapthepaperelementonaatsurfaceto
removedustanddirt.
2.Inspecttheelementfortears,anoilylm,and
damagetotherubberseal.
Important:Nevercleanthepaperelementwith
pressurizedairorliquidssuchassolvents,
gasoline,orkerosene.Replacethepaperelement
ifitisdamagedorcannotbecleanedthoroughly.
InstallingtheFoamandPaper
Elements
Important:Topreventenginedamage,always
operatetheenginewiththecompletefoamand
paperaircleanerassemblyinstalled.
1.Placethefoamelementandpaperelementinto
theblowerhousing.
23
