9.Openthefuelshut-offvalveandallowthefuelto
drainintoanapprovedfuelcontaineroradrain
pan.
Note:Nowisthebesttimetoinstallanewfuel
lterbecausethefueltankisempty.
10.Installthefuellineontothefuellter.
11.Slidethehoseclampclosetothefuellterto
securethefuelline(Figure29).
ReplacingtheFuelFilter
ServiceInterval:Every100hours/Yearly(whichever
comesrst)
Thebesttimetoreplacethefuellter(Figure29)is
whenthefueltankisempty.Neverinstalladirtyfuel
lterafterithasbeenremovedfromthefuelline.
1.Parkthemachineonalevelsurface.
2.Disengagetheblades(PTO).
3.Settheparkingbrake.
4.Stoptheengineandwaitforallmovingpartsto
stop.
5.Removetheignitionkey.
6.Closethefuelshut-offvalve(Figure30).
g008278
Figure30
1.Fuelshut-offvalve
7.Squeezetheendsofthehoseclampstogether
andslidethemawayfromtheoldfuellter
(Figure30).
8.Removetheoldfuellterfromthefuelline.
9.Installanewfuellterandmovethehose
clampsclosetoit.
10.Openthefuelshut-offvalve.
ElectricalSystem
Maintenance
ReplacingtheHeadlight
Bulbs
1.Disengagetheblades(PTO).
2.Settheparkingbrake.
3.Stoptheengineandwaitforallmovingpartsto
stop.
4.Removetheignitionkey.
5.Openthehood.
6.Pulloutthebulbsocket(Figure31).
g017879
Figure31
1.Bulb2.Bulbsocket
7.Bendthewiretabsinthemetalsleeve(thathold
thebulbinplace)outoftheway;refertoFigure
32.
g017880
Figure32
1.Bulb
2.Wiretabs(3)
8.Removetheoldlightbulb.
9.Installanewlightbulb.
