Toro 74585 - Installing the Battery; Adding Water to the Battery

WARNING
Routingthebatterycablesimproperly
coulddamagethemachineandcables,
causingsparks.Sparkscancausethe
batterygassestoexplode,resultingin
personalinjury.
•Alwaysdisconnectthenegative
(black)batterycablebefore
disconnectingthepositive(red)
cable.
•Alwaysconnectthepositive(red)
batterycablebeforeconnectingthe
negative(black)cable.
8.Lifttherubbercoverupoffthepositive(red)
cable.
9.Disconnectthepositive(red)cablefromthe
batterypost(Figure34).
10.Removethebatteryholddownrod.
11.Removethebatteryfromthechassis.
InstallingtheBattery
1.Placethebatteryintothechassiswiththebattery
poststowardtherearofthemachine(Figure34).
2.Securethebatteryinthechassiswiththehold
downrod.
3.Usingtheboltandwingnut,connectthepositive
(red)cabletothepositive(+)batterypost(Figure
34).Slidetherubbercoveroverthebatterypost.
4.Usingtheboltandwingnut,connectthe
negative(black)cabletothenegative(–)battery
post(Figure34).Slidetherubbercoveroverthe
batterypost.
CheckingtheElectrolyteLevel
ServiceInterval:Beforeeachuseordaily
1.Tiptheseatforwardtoseethebattery.
2.Lookatthesideofthebattery.Theelectrolyte
mustbeuptotheupperline(Figure35).
g006918
Figure35
1.Fillercaps3.Lowerline
2.Upperline
Note:Donotallowtheelectrolytetofallbelow
thelowerline(Figure35).
3.Iftheelectrolyteislow,addtherequiredamount
ofdistilledwater;refertoAddingWatertothe
Battery(page29).
DANGER
Batteryelectrolytecontainssulfuricacid
whichisadeadlypoisonandcauses
severeburns.
•Donotdrinkelectrolyteandavoid
contactwithskin,eyesorclothing.
Wearsafetyglassestoshieldyour
eyesandrubberglovestoprotect
yourhands.
•Fillthebatterywherecleanwateris
alwaysavailableforushingtheskin.
AddingWatertotheBattery
Thebesttimetoadddistilledwatertothebatteryis
justbeforeyouoperatethemachine.Thisletsthe
watermixthoroughlywiththeelectrolytesolution.
1.Cleanthetopofthebatterywithapapertowel.
2.Removethellercaps(Figure35).
3.Slowlypourdistilledwaterintoeachbatterycell
untilthelevelisuptothelowerpartofthetube
(Figure35).
Important:Donotoverllthebattery.
Electrolyte(sulfuricacid)canseverely
corrodeanddamagethechassis.
4.Installthellercaps.
