Toro 74657 - Converting to Side Discharge

ConvertingtoSide
Discharge
ForModelswith107cm(42-inch)
MowerDecks
Themowerdeckandmowerbladesshippedwiththis
machineweredesignedforoptimummulchingand
side-dischargeperformance.
RemovingtheDischargeCoverfor
theSideDischarge
1.Parkthemachineonalevelsurfaceand
disengagetheblade-controlswitch.
2.Movethemotion-controlleversoutwardtoPARK
position,shutofftheengine,removethekey,
andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
3.Removethe2boltsandnutsthatsecurethe
dischargecovertothemower(Figure23).
g009660
Figure23
1.Capnut(1/4inch)
4.Rotatethecoverup.
2.Dischargecover5.Removethecover.
3.Bolt(1/4x2-1/2inches)
4.Removethedischargecover.
5.Liftupthegrassdeectorandlocatethelocknut
onthedeector-pivotrod.
6.Removetheexistingthinnut(3/8inch).
7.Installthecutoffbafetotheexposedpivotrod
(Figure24).
Note:Usetheexistingthinnut(3/8inch)to
securethebafetothemower.
Note:Thecutoffbafewasshippedwiththe
machineasaloosepart.
g005667
Figure24
1.Pivotrod
3.Existingthinnut(3/8inch)
2.Cutoffbafe(originally
shippedwiththemachine)
8.Torquethefastenerto7to9N∙m(14to18ft-lb).
9.Lowerthegrassdeectoroverthedischarge
opening.
Important:Ensurethatthemowerhas
ahingedgrassdeectorthatdisperses
clippingstothesideanddowntowardthe
turf,whileinside-dischargemode.
InstallingtheDischargeCoverfor
Mulching
1.Parkthemachineonalevelsurfaceand
disengagetheblade-controlswitch.
2.Movethemotion-controlleversoutwardtothe
PARKposition,shutofftheengine,removethe
key,andwaitforallthemovingpartstostop
beforeleavingtheoperatingposition.
3.Removethecutoffbafefromthemowerdeck
(Figure24).
4.Liftthegrassdeectorandslidethetabsontop
ofthedischargecoverunderthegrassdeector
retainingrod.
5.Rotatethedischargecoverdownoverthe
opening,andontothelowerlipofthemower
(Figure25).
27
