Toro 74657 - Replacing the Grass Deflector

ReplacingtheGrass
Deector
ServiceInterval:Beforeeachuseordaily—Inspect
thegrassdeectorfordamage.
WARNING
Anuncovereddischargeopeningcould
allowthelawnmowertothrowobjectsin
theoperator'sorbystander'sdirectionand
resultinseriousinjury.Also,contactwiththe
bladecouldoccur.Neveroperatethemachine
withoutthegrassdeector,thedischarge
cover,orthegrass-collectionsysteminplace.
Neveroperatethemachinewithoutthe
grassdeector,thedischargecover,orthe
grass-collectionsysteminplace.
Inspectthegrassdeectorfordamagebeforeeach
use.Replaceanydamagedpartsbeforeuse.
1.Removethenut(3/8inch)fromtherodunder
themower(Figure67).
g005192
Figure67
1.Mowerdeck
5.Spring
2.Grassdeector6.Nut(3/8inch)
3.Grass-deectorbracket7.Shortstandoff
4.Rod
2.Slidetherodoutoftheshortstandoff,spring,
andthegrassdeector(Figure67).
3.Removethedamagedorworngrassdeector.
4.Replacethegrassdeector(Figure67).
5.Slidetherod(straightend),throughthe
rear-grass-deectorbracket.
6.Placethespringontherod,withtheendwires
downandbetweenthegrass-deectorbrackets.
7.Sliderodthroughthesecondgrass-deector
bracket(Figure67).
8.Inserttherodatthefrontofthegrassdeector
intotheshortstandoffonthedeck.
9.Securetherearendoftherodintothemower
withanut(3/8inch)asshowninFigure67.
Important:Thegrassdeectormustbe
springloadedandinthedownposition.Lift
thedeectoruptotestthatitsnapstothe
fullydownposition.
51
