Pre-Maintenance
Procedures
RaisingtheSeat
Makesurethatthemotion-controlleversarelockedin
thePARKposition,andlifttheseatforward.
Thefollowingcomponentscanbeaccessedbyraising
theseat:
•Serialplate
•Servicedecal
•Seat-adjustmentbolts
•Fuellter
•Batteryandbatterycables
ReleasingtheMower-Deck
Curtain
Loosenthe2bottomboltsofthecurtaintoaccessthe
topofthemowerdeck(Figure32).
g027794
Figure32
1.Bottombolt
2.Curtain
Note:Alwaystightentheboltstoconnectthecurtain
aftermaintenance.
Lubrication
GreasingtheBearings
ServiceInterval:Every25hours—Greaseall
lubricationpoints.
GreaseType:No.2lithiumgrease
1.Parkthemachineonalevelsurface,and
disengagetheblade-controlswitch.
2.Movethemotion-controlleversoutwardtothe
PARKposition,shutofftheengine,removethe
key,andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
3.Cleanthegreasettings(Figure33andFigure
34)witharag.
Note:Makesuretoscrapeanypaintoffthe
frontofthetting(s).
g014522
Figure33
1.Frontcastertire
decal106-8717
Figure34
Locatedontheseat-panunderside
1.Readtheinstructions
beforeservicingor
performingmaintenance
3.Greaseevery25operating
hours
2.Checkthetirepressure
every25operatinghours
4.Engine
4.Connectagreaseguntoeachttingandpump
greaseintothettingsuntilgreasebeginsto
