Toro 74824 - Checking the Engine Oil Level; Operating the Parking Brake; Operating the Throttle; Operating the Choke

FillingtheFuelTank
Note:Donotllthefueltankcompletelyfull,thiswill
allowgasolinetoexpand.
1.Shuttheengineoffandsettheparkingbrake.
2.Cleanaroundthefueltankcap.
3.Fillthefueltanktothebottomoftheller
neckFigure10.
G010016
G010475
1
2
4
3
Figure10
CheckingtheEngineOilLevel
Beforeyoustarttheengineandusethemachine,check
theoillevelintheenginecrankcase;refertoChecking
theEngineOilLevel.
OperatingtheParkingBrake
Alwayssettheparkingbrakewhenyoustopthe
machineorleaveitunattended.
SettingtheParkingBrake
G010078
1
2
Figure11
ReleasingtheParkingBrake
G010079
1
2
Figure12
OperatingtheThrottle
ThethrottlecontrolcanbemovedbetweenFastand
Slowpositions(Figure13).
Alwaysusethefastpositionwhenturningonthe
mowerdeckwiththebladecontrolswitch(PTO).
G008946
Figure13
OperatingtheChoke
Usethechoketostartacoldengine.
1.Iftheengineiscold,usethechoketostartthe
engine.
17
