AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,itis
recommendedtoadjusttheheightoftheanti-scalp
rollers.
1.Disengagethebladecontrolswitch(PTO),move
themotioncontrolleverstotheneutrallock
positionandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
G010233
1
2
3
4
Figure26
1.Anti-scalproller3.FlangeNut
2.Bolt4.Holespacing
PositioningtheSeat
Theseatcanmoveforwardandbackward.Positionthe
seatwhereyouhavethebestcontrolofthemachine
andaremostcomfortable.
Whilesittingintheoperator’sposition,raisetheseat
adjustmentleverslightlyandmovetheseatforwardor
backwardtothedesiredposition(Figure27).
G010016
G010232
1
Figure27
1.Adjustmentlever
ChangingtheSeatRide
Suspension
Thenumberofseatspringscanbechangedto
maximizeridercomfort.Morespringsshouldbeused
withheavieroperatorsandonroughterrain.Fewer
springsshouldbeusedwithlighteroperatorsandwhen
mowingsmooth,wellestablishedlawns.Alwayskeep
thenumberofspringsontheleftandrightsidethe
samewhenaddingandremovingsprings.
G010484
4
4
Figure28
1.Bolt3.Nut
2.Spring
4.Additionalmountingholes
Uptovespringscanbesecuredtotheseatsupport
withanutandbolt,seeFigure28.
