Toro 74824 - Adjusting the Height of Cut

AdjustingtheHeightofCut
Themachineisequippedwithafootpedaldecklift
system.Theoperatorcanusethefootpedaltolift
thedeckbrieytoavoidobstaclesorlockthedeckin
thehighestheight-of-cutortransportposition.The
operatorcanusetheheightofcutleverwiththefoot
pedaltolockthedeckinaspeciccuttingheight.
UsingtheFootPedalDeckLiftSystem
Pressthepedaldowntoraisethedeck;continueto
pressthepedaluntilthedeckislockedinthetransport
positionFigure24.Pushonthedeckliftpedalwith
yourfootandraisetheheight-of-cutleverslightlyto
disengagethetransportlock.
G010016
G010219
Figure24
TransportLockPosition
AdjustingtheHeight-of-Cut
Theheight-of-cutcanbeadjustedfrom1-1/2to
4-1/2inch(38to114mm)in1/4inch(6mm)
incrementsbyrelocatingtheclevispinintodifferent
holelocations.
1.Pushonthedeckliftpedalwithyourfootandraise
themowerdecktothetransportposition(also
the4-1/2inch(114mm)cuttingheightposition)
(Figure25).
2.Toadjust,removethepinfromtheheight-of-cut
bracket(Figure25).
3.Selectaholeintheheight-of-cutsystem
correspondingtotheheight-of-cutdesiredand,
insertthepin(Figure25).
4.Pushonthedeckliftpedalwithyourfootandraise
theheight-of-cutleverslightlytodisengagethe
transportlock.Lowerthedeckslowlyuntilthepin
makescontactwiththelever.
G010236
1
2
3
4
5
Figure25
1.Deckliftpedal
4.Lockposition.lowest
height-of-cut(useonlyfor
deckremoval)
2.Cutheightpin
5.Lockposition.transport
position
3.Height-of-cutpositions
UsingtheLockPositions
Thedeckcanbelockedinthehighestheight-of-cutor
transportpositionorthelowestheight-of-cutposition.
1.Pushonthedeckliftpedalwithyourfootandraise
themowerdecktothetransportposition(also
the4.5inch(114mm)cuttingheightposition)
(Figure25).
2.Removethepinfromtheheight-of-cutbracket
(Figure25).
3.Selectaholeonthelockdecalandinsertthepin
(Figure25).
4.Pushonthedeckliftpedalwithyourfootandraise
theheight-of-cutleverslightlytodisengagethe
transportlock.Lowerthedecktoslowlyuntilthe
pinmakescontactwiththelever.
