Toro 74824 - Premaintenance Procedures; Raising the Seat; Removing the Floor Pan; Lubrication

Premaintenance
Procedures
RaisingtheSeat
Makesurethemotioncontrolleversarelockedinthe
neutrallockposition.Lifttheseatforward.
Thefollowingcomponentscanbeaccessedbyraising
theseat:
•Servicedecal
•Fuses
•Batteryandcables
RemovingtheFloorPan
G009804
1
2
Figure33
1.Screw
2.Floorpan
Lubrication
GreasingtheBearings
ServiceInterval:Every25hours—Greaseall
lubricationpoints.
GreaseType:No.2GeneralPurposeLithiumBase
Grease
1.Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothe
neutrallockposition,stoptheengine,removethe
key,andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
3.Cleanthegreasettings(Figure34andFigure32)
witharag.Makesuretoscrapeanypaintoffofthe
frontofthetting(s).
G009949
1
Figure34
1.Frontcastertire
4.Connectagreaseguntoeachtting(Figure34and
Figure32).Pumpgreaseintothettingsuntilgrease
beginstooozeoutofthebearings.
5.Wipeupanyexcessgrease.
