Figure25
Transportlockpositions
1.Transportlock3.Unlockposition—doesnot
lockthemowerdeckinto
transportposition
2.Lockposition—mower
deckwilllockintotransport
position
AdjustingtheHeight-of-CutPin
Theheightofcutisadjustedfrom25to140mm(1to
5-1/2inches)in6mm(1/4inch)incrementsbymovingthe
clevispinintodifferentholelocations.
1.Movethetransportlocktothelockposition.
2.Pushonthedeckliftpedalwithyourfoot,andraisethe
mowerdecktothetransportposition(alsothe140mm
(5-1/2inch)cutting-heightposition);referto
Figure26.
3.Toadjust,rotatethepin90degreesandremovethepin
fromtheheight-of-cutbracket(Figure26).
4.Selectaholeintheheight-of-cutbracketcorresponding
totheheightofcutdesired,andinsertthepin(Figure
26).
5.Pushonthedecklift,pullbackonthetransportlock,
andslowlylowerthemowerdeck.
1
3
2
G017027
Figure26
1.Deckliftpedal
3.Transportlock
2.Height-of-cutpin
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheightofcut,itisrecommendedto
adjusttheheightoftheanti-scalprollers.
1.Disengagethebladecontrolswitch(PTO),movethe
motioncontrolleverstotheneutrallockedposition,
andsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
22
