Toro 74906 - Servicing the High-Pressure Fuel Filter; Servicing the Fuel Tank; Electrical System Maintenance; Servicing the Battery

G008963
12
3
Figure58
1.Fuellter
3.Fuelline
2.Hoseclamp
5.Squeezetheendsofthehoseclampstogetherandslide
themawayfromthelter(Figure58).
6.Removethelterfromthefuellines.
7.Installanewlterandmovethehoseclampscloseto
thelter(Figure58).
8.Openthefuel-shutoffvalve.
Note:Itisimportanttoinstallthefuellinehosesandsecure
themwithplastictiesthesameastheywereoriginallyinstalled
atthefactory,tokeepthefuellineawayfromcomponents
thatcouldcausefuellinedamage.
ServicingtheHigh-pressure
FuelFilter
Donotattempttoservicethehigh-pressurefuellter.The
high-pressurelterisintegratedwithinthefuelpumpmodule.
Thefuellterandothercomponentsinsidethefuelpump
modulearenotserviceable.Donotattempttoopenthefuel
pumpmodule.
EnsurethatanAuthorizedServiceDealerreplacesthefuel
pumpmodulewiththehigh-pressurefuellter.
ServicingtheFuelTank
Donotattempttodrainthefueltank.Ensurethatan
AuthorizedServiceDealerdrainsthefueltank.
ElectricalSystem
Maintenance
ServicingtheBattery
ServiceInterval:Monthly
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
W ash hands after handling .
DANGER
Batteryelectrolytecontainssulfuricacidwhichisa
deadlypoisonandcausessevereburns.
Donotdrinkelectrolyteandavoidcontactwith
skin,eyesorclothing.Wearsafetyglassestoshield
youreyesandrubberglovestoprotectyourhands.
RemovingtheBattery
WARNING
Batteryterminalsormetaltoolscouldshortagainst
metalmachinecomponentscausingsparks.Sparks
cancausethebatterygasestoexplode,resulting
inpersonalinjury.
•Whenremovingorinstallingthebattery,donot
allowthebatteryterminalstotouchanymetal
partsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
machine.
WARNING
Incorrectbatterycableroutingcoulddamagethe
machineandcablescausingsparks.Sparkscan
causethebatterygasestoexplode,resultingin
personalinjury.
•Alwaysdisconnectthenegative(black)battery
cablebeforedisconnectingthepositive(red)
cable.
•Alwaysconnectthepositive(red)batterycable
beforereconnectingthenegative(black)cable.
