Figure27
1.Anti-scalproller4.Flangenut
2.Spacer
5.Bolt
3.Bushing
Figure28
1.Anti-scalproller3.Flangenut
2.Bushing4.Bolt
Figure29
1.Anti-scalproller4.Flangenut
2.Spacer
5.Bolt
3.Bushing
AdjustingtheFlowBafeCam
Locks
Thisprocedureisapplicableonlytomachineswiththeow
bafelocks.Certainmodelswillhavenutsandboltsin-place
oftheowbafelocksandcanbeadjustedthesame.
Themowerdischargeowcanbeadjustedfordifferenttypes
ofmowingconditions.Positionthecamlocksandbafeto
givethebestqualityofcut.
1.Disengagethebladecontrolswitch(PTO),movethe
motioncontrolleverstotheneutrallockedposition
andsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Toadjustthecamlocks,swingtheleveruptoloosen
thecamlock(Figure30).
4.Adjustthebafeandcamlocksintheslotstothe
desireddischargeow .
5.Swingtheleverbackovertotightenthebafeandcam
locks(
Figure30).
6.Ifthecamlocksdonotlockthebafeintoplaceorit
istootight,loosentheleverandthenrotatethecam
lock.Adjustthecamlockuntilthedesiredlocking
pressureisachieved.
G008961
1
2
3
4
Figure30
1.Unlocklever
3.Positionthebafe
2.Rotatethecamlockto
increaseordecrease
lockingpressure
4.Locklever
PositioningtheFlowBafe
Thefollowingguresareonlyrecommendationsforuse.
Adjustmentswillvarybygrasstype,moisturecontent,and
heightofgrass.
Note:Iftheenginepowerdrawsdownandthemower
groundspeedisthesame,openupthebafe.
23
