Toro 74925 - Replacing the Hydraulic Pump Drive Belt

Figure76
1.Clutchpulley5.Squareholeintheidler
armfortheratchet
2.Mowerbelt6.Idlergreasezerk
3.Springloadedidlerpulley
7.Beltguide
4.Ratchet
10.Installthebeltguideontheidlerarmshownin
Figure76.
11.Usingtheratchetinthesquarehole,installtheidler
spring(Figure76).
Makesurethespringendsareseatedintheanchor
grooves.
12.Installthebeltcovers(
Figure77).
Figure77
1.Positionthebeltcover3.Ensurethetabisunder
themetalcatch
2.Slidebeltcoverunderthe
sidecatches
ReplacingtheHydraulicPump
DriveBelt
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Removemowerbelt.RefertoReplacingtheMower
BeltinMaintenance.
4.Raisethemachineandsupportitwithjackstands
(
Figure78).
49
