Toro 74925 - Adjusting the Motion Control Damper; Adjusting the Motion Control Neutral Lock Pivot

AdjustingtheMotionControl
Damper
Thetopdampermountingboltcanbeadjustedtoobtain
amoredesiredmotioncontrolleverresistance.See
Figure82formountingoptions.
Figure82
RHMotionControlShown
1.Torquethelocknutto200in-lb(16.7ft-lb).Boltmust
protrudepastendoflocknutaftertorque.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
AdjustingtheMotionControl
NeutralLockPivot
Theangednutcanbeadjustedtoobtainamoredesired
motioncontrolleverresistancewhenmovingittothe
neutrallockposition.SeeFigure83foradjustment
options.
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesiredfeel.
Formoreresistance,tightentheangednut.
Forlessresistance,loosentheangednut
3.Tightenjamnut.
Figure83
1.Flangednut2.Jamnut
52
