Toro 74925 - Cooling System Maintenance; Cleaning the Engine Screen and Engine Oil Cooler; Cleaning the Engine Cooling Fins and Shrouds; Check and Clean the Hydraulic Unit Shrouds

CoolingSystem
Maintenance
CleaningtheEngineScreen
andEngineOilCooler
ServiceInterval:Beforeeachuseordaily
Removeanybuild-upofgrass,dirtorotherdebrisfrom
theoilcooler(Figure71).
G008804
Figure71
Beforeeachuseremoveanybuild-upofgrass,dirtor
otherdebrisfromtheenginescreen.Thiswillhelp
insureadequatecoolingandcorrectenginespeedand
willreducethepossibilityofoverheatingandmechanical
damagetotheengine(
Figure72).
CleaningtheEngineCooling
FinsandShrouds
ServiceInterval:Every100hours/Yearly(whichever
comesrst)
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Removetheairintakescreen,recoilstarterandfan
housing(Figure72).
4.Cleanthedebrisandgrassfromtheengineparts.
5.Installairintakescreen,recoilstarterandfanhousing
(
Figure72).
Figure72
1.Engineguard4.Fanhousing
2.Engineairintakescreen
5.Screw
3.Bolt
CheckandCleantheHydraulic
UnitShrouds
ServiceInterval:Beforeeachuseordaily
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Raisetheseat.
4.Cleanthedebrisandgrassfromthehydraulicunit
shrouds(
Figure73).
5.Lowertheseat.
46
