Toro 74942TE - Page 63

Figure97
1.Clutchpulley
5.Beltguide
2.Mower-deckbelt
6.Spring-loadedidlerpulley
3.Spring-loadedidlerpulley7.Squareholeintheidler
armfortheratchet
4.Ensurethatthebelt-guide
tabhitsagainstthepivot
hub.
8.Spring
7.Removeandretainthehardwareonbothsidesofthe
deckasshowninFigure97.
g024670
Figure98
1.Rightstabilizer
2.Deckstrut(rightsideshown)
3.Removetheshoulderboltandnut.
4.Removetheshoulderboltandnut.
8.Raisethedeckstrutsandsecurethemintheup
position.
9.Slidethedeckouttotherightsideofthemachine.
63
