g027343
Figure95
1.Deck-liftpedal
3.Transportlock
2.Height-of-cutpin
6.Inserttheheight-adjustmentpinintothe7.6cm
(3inches)cutting-heightlocation.
7.Releasethetransportlockandallowthedeckto
lowertothecuttingheight.
8.Raisethedischargechute.
9.Onbothsidesofthedeck,measurefromthe
levelsurfacetothefronttipoftheblade(Postion
A)asshowninFigure96.
Note:Themeasurementshouldread7.6mm
(3inches).
g009196
Figure96
1.7.6cm(3inches)at
positionAiscorrect
3.Measureherefromthe
bladetiptothehard
surface
2.8.3cm(3-1/4inches)at
positionBiscorrect
4.MeasureatpositionAand
Bonbothsides
10.Fine-tunetheadjustmentnutonthefrontdeck
liftassemblybyturningit(Figure97).
Note:T oincreasetheheight,turnthe
adjustmentnutclockwise;todecrease,turn
counterclockwise.
Note:Ifthefrontdecklinksdonothaveenough
adjustmenttoachieveaccuratecutheight,the
single-pointadjustmentcanbeutilizedtogain
moreadjustment.
g035398
Figure97
1.Adjustmentnut3.Reardeckadjustment
2.Jamnut4.Frontdeckadjustment
66
