InfoCenter LCD Display (continued)
InfoCenter Menu Items (continued)
Service Menu
Menu Item Description
Hours Lists the total number of hours that the machine has been turned on.
Mow Time Lists the total number of hours that the reel has been turned on.
Power Use Lists the instantaneous power delivered by the battery in Watts.
Battery
Charge
Lists the current battery charge as a percent of capacity.
Battery
Current
Lists the instantaneous current delivered by the battery in Amps.
Battery
Volts
Lists the battery potential in volts.
Total Usage Lists the total amount of battery usage in amp hours.
Capacity List the current battery capacity in amp hours.
Charge
Cycles
Lists the total amount of battery charge cycles. A charge cycle is defined by the
process of connecting and disconnecting the charger.
Battery
Hours
Lists the total amount of hours that the battery has been active.
Backlap Sets the machine in Backlap Mode.
Energy Lists the total energy delivered by the battery over its entire life in watt-hours.
Diagnostics Menu
Menu Item Description
Key On Indicates whether the ignition key is on or off.
Traction Indicates whether the traction is engaged or disengaged.
Throttle Indicates the throttle control setting in Volts (used to calculate the target rpm).
Bail Indicates the bail control settings in volts.
Target rpm Lists the desired motor rpm as indicated by the speed control setting.
Motor rpm Lists the actual motor rpm.
12V Supply Lists the sensor supply voltage #1 of the controller.
5V Supply Lists the sensor supply voltage #2 of the controller.
CAN Bus Lists the machine communication bus status.
Product Overview: Controls Page 4–7 3460-892 A
