Governor and Throttle Control Asm. Exploded View
7 ft-lbs (10 Nm)
Pinch Bolt
Governor Arm
Governor Rod
Throttle Return Spring
Governor Arm
Governor Spring
Engine Kill Switch
7 ft-lbs (10 Nm)
Throttle Limit
Screw
Throttle Control Asm.
