19
Starter, Flywheel and Engine Cover Exploded View
3
Flywheel Nut
81 ft-lbs (110 Nm)
Starter Bolts
20 ft-lbs (28 Nm)
Ignition Coil and
Alternator Bolts
7 ft-lbs (10 Nm)
Fan Shroud Bolts
7 ft-lbs (10 Nm)
Alternator
Ignition Coil
