Toro LC1P92F - Camshaft Lobe Specifications; Camshaft Journal OD

34
Camshaft Lobe Specifications
Standard
Service Limit
Intake
1.282 - 1.284”
(32.563-32.603 mm)
1.276”
(32.40 mm)
Exhaust
1.262 - 1.264”
(32.049-32.099 mm)
1.256”
(31.9 mm)
Camshaft Journal OD
Standard
Service Limit
0.6298 - 0.6293”
(15.996-15.984 mm)
0.6266”
(15.916 mm)
Check the camshaft bearing journal for scoring, wear or damage.
NOTE: Verify that the decompression mechanism moves freely.
