RUNNING A TEST SYSTEM
To test multiple Stations:
1 Select SYSTEM TEST or RUN SINGLE STATION
on the Control Dial. SINGLE STATION will
be displayed in the bottom left corner of the
screen.
2 Press and together. The display in
the bot tom left corner will change to MULTI
STATION.
3 Press or to select a Station to test.
4 Press to move to the RUN TIME for the
Station.
5 Press or to adjust the Run Time.
6 Press until the Station number is flashing and repeat steps 3 to 5 to program all Stations
to be tested.
7 Press to start the system test.
Each Station with a Run Time set will water in sequence, beginning with the one displayed when
was pressed.
Make sure that any valve that you don’t want to test has a runtime of 00min
To stop the test at any time, turn the Control Dial to OFF.
1
No RUN TIME
STATION
MIN
MULTI
STATION
01
The system may be tested by setting selected stations to water for short times. For example, you might
set Station 2 to water for 2 minutes, or multiple Stations 1, 2 and 3 to water for 1 minute each
To test a single Station:
1 Select SYSTEM TEST or RUN SINGLE STATION
on the Control Dial. SINGLE STATION will
be displayed in the bottom left corner of the
screen.
2 Press or to select a Station to test.
3 Press to move to the RUN TIME for the
Station.
4 Press or to adjust the Run Time.
5 Press to start the system test. Remaining
runtime will be dispalyed on the screen
2
No
RUN TIME
STATION
MIN
SINGLE
STATION
02
