GLOSSARY
'HP\VWL¿FWLRQ*ORVVDU\
GLOSSARY
6ZLWFK3DUNLQJ%UDNH0DQXDO372
/RFDWLRQ
The parking brake switch is located under the fuel tank
near the locking lever (Figure 16).
3XUSRVH
The parking brake switch is part of the safety interlock
system. The engine will shut down if the operator
leaves the seat without engaging the parking brake.
+RZ,W:RUNV
When the parking brake is latched, the plunger is
GHSUHVVHGFORVLQJWKHFRQWDFWV¿JXUH
7HVWLQJ
1. Disconnect the switch from the wiring harness.
2. Use a ohmmeter to test continuity between the
WHUPLQDOV¿JXUH
Plunger out – no continuity
Plunger in - continuity
)LJXUH prkbrksw
)LJXUH parkbrkswcu
